Send InquiryFully Automatic Blow Molding Machine 7200 BPH 4 Cavity
MOQ : 1 Unit
Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity Specification
- Product Type
- Fully Automatic Blow Molding Machine
- General Use
- PET Bottle Manufacturing
- Material
- Stainless Steel / Mild Steel
- Capacity
- 7200 Bottles Per Hour (BPH)
- Weight (kg)
- Approx. 5200 kg
- Type
- Plastic Blow Molding Machine
- Computerized
- Yes
- Automatic
- Yes
- Blow Moulding Type
- Stretch Blow Moulding
- Cavity Quantity
- 4 Cavity
- Clamping Force
- 400 kN
- Clamping Stroke
- 125 mm
- Mould Stroke
- 380 mm
- Stretching Stroke
- 380 mm
- Low Pressure Air Displacement
- 2.0 m3/min (7-8 Bar)
- High Pressure Air Displacement
- 4.8 m3/min (30 Bar)
- Power
- 42 kW
- Infrared Heater
- Equipped
- Voltage
- 380 V / 50 Hz (3 Phase)
- Dimension (L*W*H)
- 5580 mm 1830 mm 2100 mm
- Feature
- High Speed, Low Power Consumption, High Precision, PLC Control, Servo System
- Color
- Standard/Customizable (Image shows White and Blue)
- Safety Features
- Automatic Alarm, Emergency Stop, Safety Doors
- Preform Loader
- Automatic
- Mould Change Time
- Within 30 minutes
- Control System
- PLC with Touchscreen HMI
- Bottle Height Range
- 80 mm - 340 mm
- Noise Level
- < 75 dB
- Bottle Diameter Range
- 50 mm - 100 mm
- Machine Cooling
- Water Chiller Required
- Operating Temperature
- 10C - 35C
- Service Availability
- Onsite and Remote Support
- Application
- Beverage, Pharmaceutical, Household, Cosmetics, Industrial Packaging
- Neck Diameter Range
- 28 mm - 38 mm
- Max Bottle Volume
- 2 Litres
Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity Trade Information
- Minimum Order Quantity
- 1 Unit
- Supply Ability
- 1 Unit Per Month
- Delivery Time
- 7-10 Days
About Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity
Introducing the Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity-a peerless solution for rapid and high-precision PET bottle production. Monumental in performance, this cost-effective marvel is built with a PLC control system and a redoubtable servo system, ensuring superior accuracy and operational speed. Producing up to 7200 bottles per hour, it accommodates bottle volumes up to 2 litres with effortless mould changes. Choose durability and safety, thanks to stainless steel/mild steel construction and robust safety features. Add to Cart and pick yours today for industry-leading reliability and efficiency!
A Monumental Solution for Versatile Applications
The Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity is widely used for manufacturing PET bottles in beverage, pharmaceutical, household, cosmetics, and industrial packaging. Its principal advantage lies in its high-speed operation and precision engineering, ensuring consistent quality across diverse application media. Featuring a broad neck diameter and bottle size range, it excels in delivering flexibility and adaptability for rapidly changing product demands.
Seamless Ordering, Exceptional Packaging & Swift Dispatch
Our sample policy equips potential buyers with confidence before placing a purchase order. All machines are securely packed for international transit, adhering to the highest standards. FOB Port: India. Expect a quick dispatch once your order is confirmed. Exchange and after-sales support are streamlined for worry-free ownership and to keep your production up and running.
A Monumental Solution for Versatile Applications
The Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity is widely used for manufacturing PET bottles in beverage, pharmaceutical, household, cosmetics, and industrial packaging. Its principal advantage lies in its high-speed operation and precision engineering, ensuring consistent quality across diverse application media. Featuring a broad neck diameter and bottle size range, it excels in delivering flexibility and adaptability for rapidly changing product demands.
Seamless Ordering, Exceptional Packaging & Swift Dispatch
Our sample policy equips potential buyers with confidence before placing a purchase order. All machines are securely packed for international transit, adhering to the highest standards. FOB Port: India. Expect a quick dispatch once your order is confirmed. Exchange and after-sales support are streamlined for worry-free ownership and to keep your production up and running.
FAQ's of Fully Automatic Blow Molding Machine 7200 BPH 4 Cavity:
Q: How does the Fully Automatic Blow Molding Machine ensure high precision during operation?
A: The machine utilizes a PLC control system with a touchscreen HMI and a robust servo system, allowing for precise adjustments and consistent bottle molding. This ensures uniform results in every production run.Q: What types of bottles can be manufactured with this machine?
A: With its four-cavity design, the machine can produce PET bottles ranging from 80 mm to 340 mm in height, 50 mm to 100 mm in diameter, and with a neck diameter between 28 mm and 38 mm, accommodating various industries like beverages, pharmaceuticals, and cosmetics.Q: Where is onsite support available for this machine?
A: Onsite and remote service support is available throughout India, ensuring assistance with installation, maintenance, and troubleshooting whenever required.Q: What are the main benefits of using this fully automatic blow molding machine?
A: Key benefits include high-speed production (7200 BPH), quick mould change times (within 30 minutes), low power consumption, enhanced safety features, and reliable, automated operation, making it cost-effective for large-scale manufacturing.Q: How soon can the machine be dispatched after a purchase order?
A: Upon receipt of a confirmed purchase order, the machine is carefully packed and quickly dispatched from our FOB port in India, ensuring minimal lead time before it arrives at your facility.
