Send InquiryFully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity
MOQ : 1 Unit
Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity Specification
- Product Type
- Fully Automatic Blow Molding Machine
- General Use
- PET Bottle Manufacturing
- Material
- Steel, Stainless Steel, Aluminum (for moulds)
- Capacity
- 1800-2000 BPH (Bottles Per Hour)
- Weight (kg)
- 2500-3000 kg (approx.)
- Type
- Injection Stretch Blow Moulding
- Computerized
- Yes, with HMI PLC Control
- Automatic
- Yes
- Blow Moulding Type
- Fully Automatic
- Cavity Quantity
- 3 Cavity
- Clamping Force
- 30-45 Tons (approx.)
- Clamping Stroke
- 120 mm - 150 mm (approx.)
- Mould Stroke
- 370 mm - 400 mm (approx.)
- Stretching Stroke
- 380 mm (typical, adjustable)
- Low Pressure Air Displacement
- 1000-1500 L/min
- High Pressure Air Displacement
- 3000-4000 L/min
- Power
- 30-40 kW
- Infrared Heater
- Yes, Preform Heating Section
- Voltage
- 380-415V, 3 Phase, 50/60 Hz
- Dimension (L*W*H)
- 3600 mm x 2100 mm x 2200 mm
- Feature
- High Output, Low Power Consumption, Precision Control
- Color
- White/Blue (customization possible)
- Neck Diameter Supported
- 18-38 mm
- Lubrication
- Automated Centralized System
- Conveyor System
- Automatic Bottle Ejection and Collection
- Bottle Volume Range
- 200 ml - 2 L
- Production Application
- Mineral Water, Juice, CSD, Edible Oil Bottles
- Noise Level
- < 80 dB
- Mould Change Time
- 20-30 Minutes
- Operating Temperature
- 5C - 50C
- Heating Zone
- 8-10 Zones
- Cooling System
- Integrated Water Chiller Compatible
- Safety Features
- Auto Stop, Emergency Cut-Off, Safety Guarding
- Control System
- HMI Touch Panel, Schneider/Siemens PLC
- Preform Feeder
- Automatic Rotary Feeder
Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity Trade Information
- Minimum Order Quantity
- 1 Unit
- Supply Ability
- 1 Unit Per Month
- Delivery Time
- 7-10 Days
About Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity
Experience pristine performance with our Exclusive Fully Automatic Blow Molding Machine 1800-2000 BPH (3 Cavity) - the praiseworthy solution for modern PET bottle production. Designed to handle neck diameters from 18-38 mm and bottle volumes between 200 ml and 2 litres, this stellar machine features a sophisticated HMI Touch Panel, Schneider/Siemens PLC controls, and supports mineral water, juice, CSD, and edible oil applications. With an integrated water chiller, automated lubrication, advanced safety features, and a quick-change mould system, it delivers high output and precision. Grab yours today and elevate your manufacturing to a new benchmark of excellence! Order Today to secure pristine quality and unbeatable efficiency.
Versatile Applications and Stellar Features
The Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity excels across multiple application surfaces including mineral water, juice, carbonated drinks, and edible oil bottles. Its extra features like automatic rotary preform feeder, centralized lubrication, and integrated cooling bring user convenience and longevity. Precision control via HMI ensures praiseworthy output for PET bottle manufacturing. Enjoy automatic bottle ejection, silent operation, and a safe production environment, making it ideal for demanding manufacturing settings.
Domestic Market Reach and Comprehensive Offerings
Our Fully Automatic Blow Molding Machine is widely available across India's main domestic markets. With a substantial supply ability, sample units can be dispatched promptly for evaluation. As a trusted distributor and exporter, we offer competitive list prices and flexible service options to meet diverse manufacturing requirements. Take advantage of our special pricing offers and experience a seamless procurement process today, ensuring your production stays ahead in quality and efficiency.
Versatile Applications and Stellar Features
The Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity excels across multiple application surfaces including mineral water, juice, carbonated drinks, and edible oil bottles. Its extra features like automatic rotary preform feeder, centralized lubrication, and integrated cooling bring user convenience and longevity. Precision control via HMI ensures praiseworthy output for PET bottle manufacturing. Enjoy automatic bottle ejection, silent operation, and a safe production environment, making it ideal for demanding manufacturing settings.
Domestic Market Reach and Comprehensive Offerings
Our Fully Automatic Blow Molding Machine is widely available across India's main domestic markets. With a substantial supply ability, sample units can be dispatched promptly for evaluation. As a trusted distributor and exporter, we offer competitive list prices and flexible service options to meet diverse manufacturing requirements. Take advantage of our special pricing offers and experience a seamless procurement process today, ensuring your production stays ahead in quality and efficiency.
FAQ's of Fully Automatic Blow Molding Machine 1800-2000 BPH 3 Cavity:
Q: How does the Fully Automatic Blow Molding Machine enhance bottle production efficiency?
A: This machine streamlines PET bottle production with automatic ejection, rapid mould change (20-30 minutes), high-capacity output (1800-2000 BPH), and precision HMI controls, enabling consistent, high-speed operations.Q: What bottles and applications can this machine handle?
A: It supports neck diameters of 18-38 mm and bottle volumes from 200 ml to 2 litres, making it ideal for mineral water, juices, CSD (carbonated soft drinks), and edible oil bottle manufacturing.Q: Where are these machines supplied and is a sample unit available?
A: We dispatch machines and sample units across India's main domestic market to distributors, manufacturers, exporters, and other stakeholders. Please contact us to request a sample and discuss supply terms.Q: What is the process for changing moulds, and how long does it take?
A: The mould change process is efficient and straightforward, typically taking 20-30 minutes, allowing flexible bottle size adjustments for varied production needs.Q: What key benefits does the machine offer for operators and manufacturers?
A: Operators benefit from automated lubrication, low noise (<80 dB), automatic rotary preform feeding, advanced safety features, and integrated cooling-all contributing to a safer, smoother, and more productive manufacturing environment.
