Send InquiryMineral Water Plant
MOQ : 10 Units
Mineral Water Plant Specification
- Water in conductivity
- <2000 S/cm
- Ph Level
- 6.5-8.5
- Frequency
- 50 Hz
- Flow Rate
- Variable (based on capacity)
- Pump Type
- Centrifugal, High Pressure Pump
- Technology
- Reverse Osmosis, UV, Ozonation
- Power Consumption
- 4-10 kW (depending on capacity)
- Usage & Applications
- Industrial and Commercial Mineral Water Bottling
- Recycle Rate
- Up to 75%
- Feature
- Corrosion Resistant, Low Maintenance, High Efficiency
- Water Out Conductivity
- <10 S/cm
- Noise Level
- <70 dB
- Efficiency (%)
- >96%
- Product Type
- Mineral Water Filtration and Packaging Plant
- Water Source
- Borewell, River, Municipal supply
- Volume
- Customizable as per plant size
- Power Source
- Electric
- Voltage
- 220-240 V
- Drive Type
- Electric Motor
- Automatic Grade
- Automatic
- Material
- Stainless Steel 304/316
- Purity Level
- Up to 99.9%
- Filter Type
- Multi-Stage (Carbon, Sand, Micron, UF, RO)
- Capacity
- 500 to 20,000 LPH
- Installation Type
- Prefabricated/Skid Mounted
- Control Panel
- PLC Based Automatic Operation
- Disinfection
- UV Sterilizer, Ozone Generator
- Compliance
- Meets BIS and FSSAI Standards
- Inlet Pressure Requirement
- 2-4 Bar
- Product Water Storage Tank
- Food Grade SS 304
- Bottle Filling System
- Fully Automatic Rinsing, Filling and Capping
- Cleaning System
- CIP (Clean-In-Place) Facility
- Packaging Options
- PET Bottles, Glass Bottles, Sachet Pouches
- Operating Temperature Range
- 5°C to 45°C
- Weight
- Depends on configuration, approx. 800-2500 kg
- Pre-treatment System
- Sand Filter, Activated Carbon Filter
- Dimensions
- Customized based on plant capacity
Mineral Water Plant Trade Information
- Minimum Order Quantity
- 10 Units
- Main Export Market(s)
- Western Europe, Middle East, Asia, North America, Africa
About Mineral Water Plant
FRP Mineral Water Plant
Product details
|
Service |
ISI License |
|
Type of Certification |
New Certification |
|
Type of Industry |
Manufacturing |
|
Type of Service Provider |
Individual Consultant |
|
Location |
Any Where in India |
|
Duration |
1-3months |
|
Product Type |
Mineral Water,AAC Block,PVC Pipe |
Advanced Automation for Hassle-free Operation
Featuring a PLC-based control panel, the entire mineral water bottling processfrom rinsing to cappingis fully automated. This significantly reduces manual intervention, ensures consistent output, and improves operational efficiency, making it a reliable solution for both large and small-scale operations.
Comprehensive Multi-Stage Filtration and Disinfection
The system employs several filtration stages: sand filter, activated carbon filter, micron filtration, ultrafiltration (UF), and reverse osmosis (RO). Essential disinfection is achieved using UV sterilizer and ozone generator, ensuring product water purity up to 99.9% and safe for consumption.
Robust and Food-Grade Construction
Manufactured from high-grade stainless steel (SS 304/316) and equipped with food-grade storage tanks, the plant ensures both strength and hygiene. Its corrosion-resistant build and skid-mounted design simplify installation and long-term maintenance, catering to demanding industrial environments.
FAQs of Mineral Water Plant:
Q: How does the fully automatic PLC-based control panel improve the plants operation?
A: The PLC-based control panel automates all major processes, including rinsing, filling, and capping, ensuring precise control over operations. This leads to increased efficiency, consistent product quality, and reduced need for manual supervision, thereby minimizing errors and downtime.Q: What is the filtration and disinfection process used in this mineral water plant?
A: The plant uses a multi-stage filtration process comprising sand and activated carbon filters, followed by micron, ultrafiltration (UF), and reverse osmosis (RO). For disinfection, UV sterilizers and ozone generators are implemented, achieving water purity levels up to 99.9% and ensuring compliance with BIS and FSSAI standards.Q: Where can this mineral water bottling plant be installed and operated?
A: This plant is suitable for installation in industrial and commercial settings and can utilize water sources including borewells, rivers, or municipal supply. Its prefabricated, skid-mounted design allows flexible placement and efficient operation in bottling facilities across India and beyond.Q: What are the available packaging options for bottled water produced by this plant?
A: The plant accommodates multiple packaging formats including PET bottles, glass bottles, and sachet pouches. This flexibility enables businesses to cater to varying market demands and distribution channels.Q: When is cleaning or maintenance required, and how is it performed?
A: With a Clean-In-Place (CIP) facility, routine cleaning and maintenance are carried out with minimal system disassembly. This automated process ensures the system remains hygienic, maintains operational efficiency, and complies with health regulations.Q: What are the key benefits of using this mineral water plant for bottling operations?
A: Some of the main benefits include high operational efficiency (>96%), low maintenance, reliable corrosion resistance, high water purity, and compliance with strict quality standards. The plants automation also reduces labor costs and enhances production rates.Q: How does the plant ensure compliance with Indian regulatory standards?
A: This mineral water plant is designed to meet both BIS and FSSAI regulations. Its comprehensive filtration, disinfection, and food-grade component selection ensure that the produced water consistently adheres to Indian safety and quality requirements.
