Semi Automatic Blow Moulding Machine

Semi Automatic Blow Moulding Machine
Send Inquiry
Product Code : DT-11
Brand Name : DTPPL-1100bph
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Unit/Units
  • Price
  • 765000 INR
Product Specifications
  • Product Type
  • Semi Automatic
  • General Use
  • PET bottles
  • Material
  • PET
  • Capacity
  • 200-5000 Milliliter (mL)
  • Weight (kg)
  • 2000 Kilograms (kg)
  • Type
  • Beverage Bottles, Oil Bottles, Water Bottles, Carbonated Drink Bottles, Juice Bottles
  • Computerized
  • Yes
  • Automatic
  • No
  • Blow Moulding Type
  • Stretch Blow Moulding
  • Cavity Quantity
  • 2-4 Pairs
  • Clamping Stroke
  • 200
  • Stretching Stroke
  • 400
  • Low Pressure Air Displacement
  • no
  • High Pressure Air Displacement
  • 38cfm/ 20hp /35bar
  • Power
  • 37hp
  • Infrared Heater
  • Yes
  • Voltage
  • 3 phase
  • Dimension(L*W*H)
  • 6*4*8 Foot (ft)
  • Color
  • off yellow
  • Warranty
  • 1 year
Product Description
DTPPL is considered as one of the highest manufacturers, dealers and service providers in the business. These machines are considered the best answer for the generation of PET bottles of various volumes (200-5000ml).
Generally utilized for the generation of water containers, oil bottles, restorative jugs and carbonated beverages bottles, the Semi-Auto Blow Molding Machine is produced as per the business models and standards.
Features:

  • Advance Service Life

  • Sensible Price.

  • Quiet Operation

  • Less Power Consumption


TECHNICALSPECIFICATIONS FOR MODEL -1100 BPH


SPECIFICATIONS

UNIT

1100 BPH

FORMING

Cavity Pitch

mm

150

Mould Thickness

mm

150 min/180 max

Clamping Stroke

mm

200 max

Stretching Stroke

mm

400 max

No. of Cavity

pcs

Two

PRODUCT

Product Height

mm

350 max

Container Volume

ml

200 min/2000 max

Neck Outer Diameter ( Max )

mm

28– 30

Product Outer Diameter( Max )

mm

90

Theoretical Production

BPH

1100

POWER

Total Connected Power

kw

11

Heating Power

kw

10

Conveyor Motor + Blower

kw

1

LAMP

Number of Lamp

pcs

06

AIR

Operation Air Pressure

kg/cm

7

Blowing Air Pressure

Kg /cm

30
